Product Description

10 Inch RY Hot oil pump Structure Characteristics：

1. Basic structure is single stage single suction cantilever feet support, pump suction is axial inhaled, discharge center vertical, and installed in a same base with motor.
2. Pump supported by double ball bearing, front end lubricated by lubricating oil, back end lubricated by grease, a guide tubing in the middle, to observe the conditions of sealing at any time and recovery of heat conduction oil.

RY Hot oil pump application scope:

1. Petro-chemical industry
2. Oill industry, hot oil circulation system
3. Synthetic-fibre
4. Textile dyeing and printing industry
5. Plastic and rubber industry
6. Papermaking industry
7. Timper process industry
8. Construction and building industry

Besides the above fields, the pumps are also proper in machinery manufacturing, food processing, medicine making and the circling system for oil supplying of the hot oil boiler, the circling system of the heating installation.

Model	Capacity m 3 /h	Lift m	Speed r/min	Power kw		Efficiency η%	Motor-Y
				Shaft power	Power Distribution
RY250-200-400	500	50	1480	86.2	110	79	315S
RY250-200-500	500	80	1480	136	160	76.5	315M
RY250-200-500A	400	50	1480	75	90	73	280M
